ADS-TEC MES9000 Basis 15.6" Full-HD, PCAP Multi-Touch, Intel Core i5, 230V AC

DVG-MES9016-031-BZ

ads-tec

DVG-MES9016-031-BZ

S-021-155930

New

MES9000 as an HMI panel PC impresses not only with its high performance and simple integration into the machine or system, but also with the outstanding user-friendliness of the large multi-touch display and the contemporary design.

More details

Prices are only visible for registered customers. Create an account now.

Data sheet

On, off switch Yes
Length 400.00 Millimeter
Splinter protection No
Standards / Approvals No information
Width 270.00 Millimeter
Portection rating IP65
Display size 15.6"
Resolution Not specified
Height 88.00 Millimeter
Min. ambient temperature 0.00 Celsius
Input voltage range 230 V
Touchscreen PCAP Multi-Touch
Brightness (cd/m²) 450
Operating system IGEL Linux, Windows 10 IoT Enterprise 2021 LTSC
Max. ambient temperature 40.00 Celsius
Voltage Range (Min.) 0.00 Volt
Voltage Range (Max.) 0.00 Volt
Power consumption (W) 0.00 Watt
Operation humidity not specified
CPU Intel® Core™ i5-8365UE 1,6 GHz
RAM 8.00 Gigabyte
Memory / Flash 128.00 Gigabyte
Analog Interfaces 1 x Smartcard-Reader für ADS-TEC Big-LinX, 1 x DisplayPort++ (1.2)
Ethernet interfaces 3 x Ethernet (10/100/1000 Mbit/s)
USB interfaces 4 x USB 3.1 Gen. 2
JMobile usable? No
